CD4027

CD4027

€0,35 €0,30
  • Availability: In stock
  • Delivery time:Will be shipped within 24 hours
Dual JK master
scavb flipflop
Type CD4027 ...More information
  • Gratis verzending vanaf 50 Euro
  • Verzending al vanaf 2.50 Euro
  • Kans op een gratis product dat bij jouw order past
  • Doorgaans op werkdagen, binnen 24 uur verzonden.

Product description

  • Availability: In stock
  • Delivery time:Will be shipped within 24 hours
  • Unit price:€0,30 / Piece

Description

These dual J-K flip-flops are monolithic complementary
MOS (CMOS) integrated circuits constructed with N- and Pchannel
enhancement mode transistors. Each flip-flop has
independent J, K, set, reset, and clock inputs and buffered
Q and Q outputs. These flip-flops are edge sensitive to the
clock input and change state on the positive-going transition
of the clock pulses. Set or reset is independent of the clock
and is accomplished by a high level on the respective input.
All inputs are protected against damage due to static discharge
by diode clamps to VDD and VSS

Features

Wide supply voltage range 3.0V to 15V
High noise immunity 0.45 VDD (typ.)
Low power TTL Fan out of 2 driving 74L compatibility or 1 driving 74LS
Low power 50 nW (typ.)
Medium speed operation 12 MHz (typ.) with 10V supply
